MSI MPG B760I EDGE WIFI

Chipset
- INTEL B760

CPU
- Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
- LGA 1700

Memory
- 2x DDR5, Maximum Memory Capacity 128GB
- Supports Dual-Channel mode

Onboard Graphics
- 1x HDMI™
Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*
- 1x DisplayPort
Support DP 1.4, maximum resolution of 8K 60Hz*

Slot
- 1x PCI-E x16 slot
- PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

Audio
- Realtek® ALC897 Codec
- 7.1-Channel High Definition Audio

Storage
- 2x M.2
- 4x SATA 6G

LAN
- Realtek® RTL8125BG 2.5Gbps LAN

WIRELESS LAN & BLUETOOTH
- Intel® Wi-Fi 6E
- The Wireless module is pre-installed in the M.2 (Key-E) slot
- Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
- Supports 802.11 a/ b/ g/ n/ ac/ ax
- Supports Bluetooth® 5.3, FIPS, FISMA

OPERATING SYSTEM
- Support for Windows® 11 64-bit, Windows® 10 64-bit

PCB Info
- Mini-ITX
- 170mmx170mm
