ASROCK B660M Steel Legend

Product image 1
Product image 2
Product image 3

ASROCK B660M Steel Legend

Unique Features
  • 9 Power Phase Design, Dr.MOS
  • Mendukung Memori DDR4
  • PCB 6 Layer
  • Dragon 2.5G LAN
  • I/O Armor dan Heatsink Steel Legend
CPU (Soket) Mendukung Prosesor Intel® Core™ Generasi ke-13 & ke-12 (LGA1700).
Chipset Intel® B660
Memory Dual Channel DDR4 Memory Technology
4 x DDR4 DIMM Slots
Kapasitas Maksimal: 128GB
Mendukung DDR4 non-ECC, un-buffered memory hingga 5000+(OC)
Expansion Slots 1 x PCIe 4.0 x16 Slot (mode x16)
1 x PCIe 3.0 x16 Slot (mode x4)
1 x PCIe 3.0 x1 Slot
1 x M.2 Socket (Key E) untuk Modul WiFi/BT*
*Modul WiFi dijual terpisah.
Storage (M.2 & SATA) Total 2x M.2 Slots:
1 x Hyper M.2 (PCIe Gen4x4 - 64 Gb/s) (Dari CPU)
1 x Hyper M.2 (PCIe Gen4x4 - 64 Gb/s) (Dari Chipset)
4 x SATA3 6.0 Gb/s Connectors
Graphics Output 1 x HDMI 2.1 Port (Max. 4K 60Hz)
1 x DisplayPort 1.4 (Max. 8K 60Hz / 5K 120Hz dengan DSC)
*Memerlukan CPU dengan Grafis Terintegrasi.
Audio 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Nahimic Audio
LAN Dragon RTL8125BG 2.5 Gigabit LAN (2.5 Gb/s)
Rear Panel I/O 2x Antenna Mounting Points (untuk modul WiFi opsional)
1x HDMI, 1x DisplayPort 1.4
1x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
1x USB 3.2 Gen2 Type-A Port (10 Gb/s)
2x USB 3.2 Gen1 Type-A Ports (5 Gb/s)
2x USB 2.0 Ports
1x RJ-45 LAN Port, 1x Optical SPDIF Out Port
HD Audio Jacks, 1x BIOS Flashback Button
Form Factor Micro ATX Form Factor (24.4 cm x 24.4 cm)
OS Microsoft Windows® 11 64-bit / Windows 10 64-bit
$35.74

Original: $119.12

-70%
ASROCK B660M Steel Legend—

$119.12

$35.74

Product Information

Shipping & Returns

Description

Unique Features
  • 9 Power Phase Design, Dr.MOS
  • Mendukung Memori DDR4
  • PCB 6 Layer
  • Dragon 2.5G LAN
  • I/O Armor dan Heatsink Steel Legend
CPU (Soket) Mendukung Prosesor Intel® Core™ Generasi ke-13 & ke-12 (LGA1700).
Chipset Intel® B660
Memory Dual Channel DDR4 Memory Technology
4 x DDR4 DIMM Slots
Kapasitas Maksimal: 128GB
Mendukung DDR4 non-ECC, un-buffered memory hingga 5000+(OC)
Expansion Slots 1 x PCIe 4.0 x16 Slot (mode x16)
1 x PCIe 3.0 x16 Slot (mode x4)
1 x PCIe 3.0 x1 Slot
1 x M.2 Socket (Key E) untuk Modul WiFi/BT*
*Modul WiFi dijual terpisah.
Storage (M.2 & SATA) Total 2x M.2 Slots:
1 x Hyper M.2 (PCIe Gen4x4 - 64 Gb/s) (Dari CPU)
1 x Hyper M.2 (PCIe Gen4x4 - 64 Gb/s) (Dari Chipset)
4 x SATA3 6.0 Gb/s Connectors
Graphics Output 1 x HDMI 2.1 Port (Max. 4K 60Hz)
1 x DisplayPort 1.4 (Max. 8K 60Hz / 5K 120Hz dengan DSC)
*Memerlukan CPU dengan Grafis Terintegrasi.
Audio 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Nahimic Audio
LAN Dragon RTL8125BG 2.5 Gigabit LAN (2.5 Gb/s)
Rear Panel I/O 2x Antenna Mounting Points (untuk modul WiFi opsional)
1x HDMI, 1x DisplayPort 1.4
1x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
1x USB 3.2 Gen2 Type-A Port (10 Gb/s)
2x USB 3.2 Gen1 Type-A Ports (5 Gb/s)
2x USB 2.0 Ports
1x RJ-45 LAN Port, 1x Optical SPDIF Out Port
HD Audio Jacks, 1x BIOS Flashback Button
Form Factor Micro ATX Form Factor (24.4 cm x 24.4 cm)
OS Microsoft Windows® 11 64-bit / Windows 10 64-bit
