FORMULA V LINE FV-750BD

General
Model FV-750BD
Dimension 140 x 150 x 86mm
Real Watts 750W
Efficiency 80Plus Bronze
Input Voltage Full range
Type ATX3.1
Main Capacitor Japanese Capacitor
PFC APFC
Fan 120mm
Modular Direct Cable
AC Input
AC 100-240V~, 8A, 50-60Hz
DC Output
3.3V 20A
5V 20A
+12V 62.5A
-12V 0.3A
+5Vsb 3A
Total Power 750W
Cable SPEC
Mainboard 20+4P(550mm) x1
CPU P8(4+4)(600mm)to(P4+4)(150mm) x1
PCI-E P8(6+2)(500mm)to(6+2)(150mm) x1
PCIe 5.1 PCIe 5.1 H++ 12V-2X6 12VHPWR 16 Pin (600W, 600mm) x1
SATA / IDE 1 SATA(400mm) / SATA(150mm)/SATA(150mm)/MOLEX(150mm) x1
SATA / IDE 2 SATA(400mm) / SATA(150mm)/MOLEX(150mm)/MOLEX(150mm) x1
$12.55

Original: $41.83

-70%
FORMULA V LINE FV-750BD—

$41.83

$12.55

Product Information

Shipping & Returns

Description

General
Model FV-750BD
Dimension 140 x 150 x 86mm
Real Watts 750W
Efficiency 80Plus Bronze
Input Voltage Full range
Type ATX3.1
Main Capacitor Japanese Capacitor
PFC APFC
Fan 120mm
Modular Direct Cable
AC Input
AC 100-240V~, 8A, 50-60Hz
DC Output
3.3V 20A
5V 20A
+12V 62.5A
-12V 0.3A
+5Vsb 3A
Total Power 750W
Cable SPEC
Mainboard 20+4P(550mm) x1
CPU P8(4+4)(600mm)to(P4+4)(150mm) x1
PCI-E P8(6+2)(500mm)to(6+2)(150mm) x1
PCIe 5.1 PCIe 5.1 H++ 12V-2X6 12VHPWR 16 Pin (600W, 600mm) x1
SATA / IDE 1 SATA(400mm) / SATA(150mm)/SATA(150mm)/MOLEX(150mm) x1
SATA / IDE 2 SATA(400mm) / SATA(150mm)/MOLEX(150mm)/MOLEX(150mm) x1
