NZXT H7 Flow RGB
| Enclosure Type | Mid-Tower |
| Motherboard Support | E-ATX (Up to 277 mm), ATX, Micro-ATX, Mini-ITX |
| Case Material | SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted (Black) |
| Expansion Slots | 7 (Standard) |
| Filters | High-Performance Mesh |
| Height (with feet) | 544 mm (21.42 in) |
| Width | 244 mm (9.61 in) |
| Depth | 468 mm (18.43 in) |
| Weight | 11.13 kg (24.54 lb) |
| 2.5" Drive Bays | 2 + 2 |
| 3.5" Drive Bays | 2 |
| Front I/O Ports (USB 3.2 Gen 1 Type-A) | 2 |
| Front I/O Ports (USB 3.2 Gen 2x2 Type-C, 20 Gbps) | 1 |
| Front I/O Ports (Headset Audio Jack) | 1 |
| CPU Cooler Height Clearance | Up to 185 mm (7.28 in) |
| GPU Length Clearance | Up to 410 mm (16.14 in) |
| PSU Length Clearance | Up to 200 mm (7.87 in) |
| Cable Management Space | Up to 34.5 mm (1.36 in) |
| Top Radiator/Fan Combined Thickness (140mm / 280mm) | Up to 57 mm (2.24 in) |
| Cooling Feature | Location | Max Size / Detail |
|---|---|---|
| Fan Support | ||
| Front | 3 x 120 mm / 3 x 140 mm | |
| Top | 3 x 120 mm / 2 x 140 mm | |
| Bottom | 3 x 120 mm | |
| Rear | 1 x 120 mm / 1 x 140 mm | |
| Pre-installed Fan (H7 Flow RGB) | ||
| Front | 3 x F120 RGB Core Fan (Case Version) | |
| Rear | None | |
| Radiator Support | ||
| Front | Up to 420 mm | |
| Top | Up to 360 mm | |
| Rear | Up to 140 mm | |
| F120 RGB Core Fan Specifications (Case Version) | |
|---|---|
| Speed | 1,350 ± 135 RPM |
| Airflow | 55.17 CFM |
| Static Pressure | 1.27 mm - H₂O |
| Noise | 26.1 dBA |
| Fan Connector | 3-pin DC |
