NZXT H5 Flow RGB
| Enclosure Type | Mid-Tower Case |
| Motherboard Compatibility | Mini-ITX, Micro-ATX, ATX, and EATX (Up to 277 mm wide) |
| Case Material | SGCC Steel, Ultra-Clear Tempered Glass (White Variant), Dark Tinted Tempered Glass (Black Variant) |
| Expansion Slots | 7 |
| Height (with feet) | 465 mm (18.31 in) |
| Width | 225 mm (8.86 in) |
| Depth | 430 mm (16.93 in) |
| Weight | Approx. 7.28 kg (16.04 lb) |
| 2.5" Drive Bays | 2 |
| 3.5" Drive Bays | 1 |
| Front I/O Ports (USB 3.2 Gen 1 Type-A) | 1 |
| Front I/O Ports (USB 3.2 Gen 2 Type-C) | 1 |
| Front I/O Ports (Headset Audio Jack) | 1 |
| CPU Cooler Height Clearance | Up to 170 mm |
| GPU Length Clearance | Up to 410 mm |
| PSU Length Clearance | Up to 200 mm |
| Cable Management Space | Up to 28.7 mm |
| Top Mounted Radiator + Fan Thickness | Up to 55 mm |
| Cooling Feature | Location | Max Size / Detail |
|---|---|---|
| Fan Support | ||
| Front | 3 x 120 mm / 2 x 140 mm | |
| Top | 2 x 120 mm / 2 x 140 mm | |
| Rear | 1 x 120 mm | |
| Bottom | 2 x 120 mm | |
| Pre-installed Fan | ||
| Rear | 1x F120Q (Case Version) | |
| Front |
F360 RGB Core (Case Version)
|
|
| Radiator Support | ||
| Front | Up to 360 mm | |
| Top | Up to 240 mm (280 mm with low-profile RAM) |
