NOCTUA NF-S12B redux-1200 PWM

Specifications :
MODEL NAME
- NOCTUA NF-S12B redux-1200 PWM
COLOR
- Grey (Two-tone Redux Edition)
FAN DIMENSIONS
- 120 x 120 x 25 mm
LIGHTING
- Non-LED (Classic Industrial Aesthetic)
FAN SPECIFICATIONS
- Fan Speed: 400 - 1,200 ± 10% RPM
- Airflow: 100.6 m³/h (59.2 CFM)
- Static Pressure: 1.31 mm-H2O
- Noise: 18.1 dBA
- Bearing: SSO (Self-Stabilising Oil-Pressure)
ELECTRICAL SPECIFICATIONS
- Rated Voltage: 12V DC
- Max. Input Current: 0.075A
- Max. Input Power: 0.9W
CONNECTOR & CABLES
- 4-pin PWM
- Cable Length: 40 cm
SPECIAL FEATURES
- Bevelled Blade Tips (High airflow efficiency)
- Low-Noise Performance for Case Cooling
- SSO Bearing Technology
- 150,000+ hours MTTF
WARRANTY
- 6 years
$3.52

Original: $11.74

-70%
NOCTUA NF-S12B redux-1200 PWM—

$11.74

$3.52
