MONTECH CENTURY 850W GOLD
| Product Name | CENTURY 850 |
| ATX Version | ATX12V |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240Vac |
| Input Current | 12A |
| Input Frequency | 47-63Hz |
| Dimensions (L*B*H) | 140*150*86mm |
| Fan Size | 120mm ( FDB Fan ) |
| Hold Up Time | 10msec (minimum) at 80% of full load at 230Vac input. |
| Efficiency | 90% Typically |
| MTBF | >100,000 Hours |
| Operating Temperature | 0-45°C |
| Protections | OCP/OVP/UVP/OPP/SCP/OTP |
| Regulatory | cTUVus / TUV / CB / CE / RoHS / FCC |
| Connectors | M/B 20+4Pin : 1 CPU 4+4Pin : 2 PCIE 6+2 : 6 SATA : 10 Molex 4Pin : 3 FDD : 1 |
| AC Input | 100-240Vac 47-63Hz 12.0A |
| DC Output | +3.3V +5V 12V -12V +5VSB |
| Max. Output Current | 20A 20A 70.5A 0.3A 2.5A |
| Max. Output Power | 110W 846W 3.6W 12.5W |
| Total POWER | 850W |
$79.00
MONTECH CENTURY 850W GOLD—
$79.00
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
| Product Name | CENTURY 850 |
| ATX Version | ATX12V |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240Vac |
| Input Current | 12A |
| Input Frequency | 47-63Hz |
| Dimensions (L*B*H) | 140*150*86mm |
| Fan Size | 120mm ( FDB Fan ) |
| Hold Up Time | 10msec (minimum) at 80% of full load at 230Vac input. |
| Efficiency | 90% Typically |
| MTBF | >100,000 Hours |
| Operating Temperature | 0-45°C |
| Protections | OCP/OVP/UVP/OPP/SCP/OTP |
| Regulatory | cTUVus / TUV / CB / CE / RoHS / FCC |
| Connectors | M/B 20+4Pin : 1 CPU 4+4Pin : 2 PCIE 6+2 : 6 SATA : 10 Molex 4Pin : 3 FDD : 1 |
| AC Input | 100-240Vac 47-63Hz 12.0A |
| DC Output | +3.3V +5V 12V -12V +5VSB |
| Max. Output Current | 20A 20A 70.5A 0.3A 2.5A |
| Max. Output Power | 110W 846W 3.6W 12.5W |
| Total POWER | 850W |
