GIGABYTE X870M AORUS ELITE WIFI7
| CPU | - AMD Socket AM5 |
| Chipset | - AMD X870 |
| Memory | - Support for DDR5 - 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory - Dual channel memory architecture |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon Graphics support+ASMedia USB4 Controller: - 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz Integrated Graphics Processor with AMD Radeon Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz |
| Audio | - Realtek ALC1220 CODEC - High Definition Audio - 2/4/5.1/7.1-channel - Support for S/PDIF Out |
| LAN | - Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Realtek Wi-Fi 7 RTL8922AE - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard |
| Expansion Slots | - 1 x PCI Express x16 slot (PCIEX16) Chipset: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| Storage Interface | - 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs - 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs - 2 x SATA 6Gb/s connectors |
| Bundled Software | - Norton Internet Security (OEM version) |
| Operating System | - Support for Windows 11 64-bit |
| Form Factor | - Micro ATX Form Factor; 24.4cm x 24.4cm |
$88.48
Original: $294.94
-70%GIGABYTE X870M AORUS ELITE WIFI7—
$294.94
$88.48Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
| CPU | - AMD Socket AM5 |
| Chipset | - AMD X870 |
| Memory | - Support for DDR5 - 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory - Dual channel memory architecture |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon Graphics support+ASMedia USB4 Controller: - 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz Integrated Graphics Processor with AMD Radeon Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz |
| Audio | - Realtek ALC1220 CODEC - High Definition Audio - 2/4/5.1/7.1-channel - Support for S/PDIF Out |
| LAN | - Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Realtek Wi-Fi 7 RTL8922AE - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard |
| Expansion Slots | - 1 x PCI Express x16 slot (PCIEX16) Chipset: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| Storage Interface | - 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs - 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs - 2 x SATA 6Gb/s connectors |
| Bundled Software | - Norton Internet Security (OEM version) |
| Operating System | - Support for Windows 11 64-bit |
| Form Factor | - Micro ATX Form Factor; 24.4cm x 24.4cm |
