GAMDIAS ATLAS M1 | Seamless Tempered Glass Display PC Case

Specifications :

Model
- ATLAS M1

Case Type
- MID Tower

MB Support
- ATX、Micro-ATX、Mini-ITX

Synchronization
- 5V 3-Pin Addressable Header

CASE Color
- Black

Expansion Slots
- 7 + 2

Material
- SPCC & ABS & Tempered glass

Window
- Front, Left

Radiator Support
- Top: 360mm、 280mm / Side: 240mm / Rear: 120mm

Fan Support
- Top: 3 x 120mm、2 x 140mm / Side: 2 x 120mm / Rear: 1 x 120mm

Pre-installed Fans
- Side : 2 x 120mm ARGB PWM Fans /
- Rear : 1 x 120mm ARGB PWM Fann

Drive Bays
- 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage)
- 2 x 2.5"(SSD Bracket)

I/O Port
- USB 3.0 x 1, Type C x 1, HD Audio x1, LED Control x1, Monitor Mode Switch x 1

Clearance
- CPU cooler height limitation:160mm
- VGA length limitation:410mm
- PSU length limitation:180mm

Dimension (L x W x H)
- 420 x 210 x 465 mm

Pre-installed Control BOX
- 6 Ports Hub (3 ports are used)
