COOLER MASTER MWE Gold 850 V2 ATX 3.1 White Edition | PSU 850W 80+ Gold Fully Modular

𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 :

Model
- MPE-8501-AFAAG-3EG**

ATX Version
- ATX 12V Ver. 3.1

PFC
- Active PFC

Input Voltage
- 100-240V

Input Current
- 12-6A

Input Frequency
- 50-60Hz

Dimensions (L x W x H)
- 160 x 150 x 86 mm

Fan Size
- 120mm

Fan Bearing
- HDB

Efficiency
- ≥90% @ Typical Load

80 PLUS Rating
- 80 PLUS Gold

ErP 2014 Lot 3
- Yes

Operating Temperature
- 0-50°C

Power Good Signal
- 100 - 150 ms

Hold Up Time
- ≥ 16ms

MTBF
- >100,000 Hours

Protections
- UVP / OVP / OPP / OTP / SCP / OCP

Regulatory
- TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA

ATX 24 Pin Connectors
- 1

EPS 4+4 Pin Connectors
- 1

EPS 8 Pin Connector
- 1

SATA Connectors
- 12

Peripheral 4 Pin Connectors
- 4

PCI-e 6+2 Pin Connectors
- 4

12V-2x6 Connectors
- 1 (1 to 3)

Category
- Above 750W

Series
- MWE Gold Series

Modular
- Fully Modular

Form Factor
- ATX

80 Plus Efficiency
- Gold

Watts
- 850W
