ASUS ROG STRIX 1000W Platinum

ROG STRIX 1000W Platinum PSU Specifications
Model ROG STRIX 1000W Platinum
Intel Form Factor ATX12V
PFC Type Active PFC
ATX Standard ATX 3.1
Dimensions 160 x 150 x 86 mm
Efficiency 80Plus Platinum
MTBF >120,000 hrs @ 25°C
Protection Features OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials ROHS
AC Input Range 100-240Vac
DC Output Voltage (Maximum Load / Combined Load) +3.3V (25A / 130W)
+5V (25A / 130W)
+12V (83.3A / 1000W)
-12V (0.3A / 3.6W)
+5Vsb (3A / 15W)
Total Output 1000W
Cable Connectors MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1 (both PSU & component side)
PCI-E 6+2-pin x 4
SATA x 6
PERIPHERAL x 3
Package Contents Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable x 2 (1000mm)
PCI-E Gen 5.1 (16-pin-to-16-pin) Cable x 1 (750mm)
PCI-E (8-pin-to-6+2pin) Cable x 4 (750mm)
SATA 1-to-3 Cable x 2 (400+120+120mm)
Peripheral 1-to-3 Cabel x 1 (400+150+150mm)
ROG Strix DIY sticker x 1
User Manual x 1
Weight 1.81 kg (single PSU)
Cybenetics Noise Level Certification A+
0dB Technology Supported. The fan shuts off entirely when the PSU is under certain load.
0dB Fan Button Yes. When the Button is ON, the fan will only spin up when the system reaches a certain load. When the Button is OFF, the fan will continuously spin at all load levels.
$62.64

Original: $208.80

-70%
ASUS ROG STRIX 1000W Platinum—

$208.80

$62.64
