ASUS ProArt B760-CREATOR WIFI | Intel B760 LGA 1700 DDR5 ATX

𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 :

Model
- ProArt B760-CREATOR WIFI

CPU
- Intel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
- Supports Intel® 10 nm CPU

Chipset
- Intel® B760 Chipset

Memory
- 4 x DIMM slots, Max. 192GB, DDR5 Non-ECC, Un-buffered Memory*
- Dual Channel Memory Architecture

Graphics
- 1 x HDMITM port**
- 1 x DisplayPort port***

Expansion Slots
- 1 x PCIe 5.0/4.0/3.0 x16 slot
- 1 x PCIe 4.0 x16 slot (supports x4 mode)
- 1 x PCIe 3.0 x1 slot**

Storage
- Total supports 3 x M.2 slots and 4x SATA 6Gb/s ports*
- M.2_1 slot (Key M), type 2242/2260/2280/22110
- M.2_2 slot (Key M), type 2242/2260/2280/22110
- M.2_3 slot (Key M), type 2242/2260/2280/22110
- 4 x SATA 6Gb/s ports

Ethernet
- 1 x Realtek 2.5Gb Ethernet
- 1 x Intel® 1Gb Ethernet
- ASUS LANGuard

Wireless & Bluetooth
- Wi-Fi 6
- 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5GHz frequency band
- Bluetooth® v5.2*

Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback

Accessories
- 2 x SATA 6Gb/s cables
- 1 x ASUS Wi-Fi moving antennas
- 2 x M.2 Rubber packages
- 1 x ProArt ruler
- 1 x Q-connector
- 1 x ACC Express Activation Key Card
- 1 x User guide

Operating System
- Windows® 11 64-bit, Windows® 10 64-bit

Form Factor
- ATX Form Factor
- 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
