1STPLAYER NGDP 1300W ATX 3.1 Platinum

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

1STPLAYER NGDP 1300W ATX 3.1 Platinum

MODEL HA-1300BA3
POWER OUTPUT 1300 W
INPUT VOLTAGE 100 - 240V
INPUT CURRENT 15 - 7.5 A
INPUT FREQUENCY 50/60 Hz
EFFICIENCY 93.15% at typical load
DIMENSIONS (L x W x H) 140 x 150 x 86 mm
MODULAR Full-modular
CERTIFICATIONS 80 PLUS Platinum
PFC Active PFC
FAN SIZE 120 mm FDB
PROTECTIONS UVP, OVP, OPP, SCP, OCP, OTP
REGULATORY CE/FCC/C-Tik/RoHS/CCC/cTUVus/IEC/EAC
MTBF 100,000 hours
CIRCUIT STRUCTURE LLC + DC - DC
WARRANTY 10 years
DC OUTPUT MAX LOAD (A) MAX OUTPUT (W)
+3.3V 20 120
+5V 20 120
+12V 108 1296
+5Vsb 3 15
-12V 0.3 3.6
CONNECTORS TOTAL LENGTH QUANTITY
ATX Cable 24-pin (MB) 610 mm 1
ATX12V Cable 8-pin (CPU 4+4) 650 mm 2
PCI-E Cable 12V-2x6 (GPU 12+4) 720 mm 1
PCI-E Cable 8-pin (GPU 6+2) 600 mm 4
SATA Cable (SSD/HDD) 465 mm 3
MOLEX Cable (4 PATA) 465 mm 1
$56.45

Original: $188.15

-70%
1STPLAYER NGDP 1300W ATX 3.1 Platinum—

$188.15

$56.45

Product Information

Shipping & Returns

Description

MODEL HA-1300BA3
POWER OUTPUT 1300 W
INPUT VOLTAGE 100 - 240V
INPUT CURRENT 15 - 7.5 A
INPUT FREQUENCY 50/60 Hz
EFFICIENCY 93.15% at typical load
DIMENSIONS (L x W x H) 140 x 150 x 86 mm
MODULAR Full-modular
CERTIFICATIONS 80 PLUS Platinum
PFC Active PFC
FAN SIZE 120 mm FDB
PROTECTIONS UVP, OVP, OPP, SCP, OCP, OTP
REGULATORY CE/FCC/C-Tik/RoHS/CCC/cTUVus/IEC/EAC
MTBF 100,000 hours
CIRCUIT STRUCTURE LLC + DC - DC
WARRANTY 10 years
DC OUTPUT MAX LOAD (A) MAX OUTPUT (W)
+3.3V 20 120
+5V 20 120
+12V 108 1296
+5Vsb 3 15
-12V 0.3 3.6
CONNECTORS TOTAL LENGTH QUANTITY
ATX Cable 24-pin (MB) 610 mm 1
ATX12V Cable 8-pin (CPU 4+4) 650 mm 2
PCI-E Cable 12V-2x6 (GPU 12+4) 720 mm 1
PCI-E Cable 8-pin (GPU 6+2) 600 mm 4
SATA Cable (SSD/HDD) 465 mm 3
MOLEX Cable (4 PATA) 465 mm 1
